A brilliant all-rounder for demanding tasks.
The e 914 is a condenser microphone of the superior class with a full-bodied sound and excellent dynamics. Its silky character, never headstrong, is developed from the gentle emphasis of the sophisticated treble. Its straightforward transient response accurately captures the temperament of each set, even at very high sound pressure levels. With its detailed resolution, the e 914 makes every live drum sound more refined. The capsule has extraordinary feedback resistance and can be individually adapted to various needs: three positions of bass roll-off/cut-off and pre-attenuation can be set.
Condenser microphone
Perfect for ambitious (live) recordings
Excellent dynamics and lively sound on a wide range of instruments
Handles very high sound pressure levels
Three-position bass roll-off/cut-off switch
Three-position pre-attenuation
Hva er med i esken
e 914 microphone
Microphone clamp MZQ 800
Windscreen
Pouch
User manual
Dimensions Ø 24 x 157 mm
Connector XLR-3
Transducer principle (Microphone) pre-polarised condenser microphone
Frequency response 20 - 20000 Hz
Weight 198 g
Attenuation 0, -10, -20 dB
Pick-up pattern cardioid
Sensitivity in free field, no load (1kHz) 7 mV/Pa
Nominal impedance 100 O
Min. terminating impedance 1000 O
Phantom powering 48 V/2,2 mA
Equivalent noise level 19 dB(A)
Max. Sound pressure level (active) - 137, 147 (with activated -10 db attenuation),
157 (with activated -20 db attenuation) db
