Frequency Response -1.5 dB @ 45Hz – 23kHz
Frequency Range 35Hz – 36 kHz
Max SPL (80 Hz - 20 kHz) > ,108 dB SPL / 1m
Maximum Peak SPL (80 Hz - 20 kHz) > ,114 dB SPL / 1m
HF Driver 2409H
LF Driver 728G
Dividing Network
Transition Frequency 1.7 kHz
Input Types 1 x XLR-1/4" balanced combination analog audio input
1 x XLR AES3 format digital input with 1 x XLR pass-through output
Digital input will accept sample rates up to 192 kHz
Dimensions (HxWxD) 17.25 x 9.75 x 11.5 in (438 x 248 x 292 mm)
Weight Each 25.2 lb (11.5 kg)
Enclosure Birch plywood reinforced for mounting
Mounting Top, bottom and rear mounting points. 4-hole mounting pattern
